Mechanical properties
Spacing: 2.54mm
Plastic parts; PA66,UL94V-0
Housing: Gold plated
Contact: Phosphor bronze
Electrical performance
Rated voltage：24V/DC
Rated current：25mA
Ambient temperature: -20℃_~+85℃
Contact resistance: 100mΩ
Insulation resistance: 100MΩ/DC500V
Withstanding Voltage: AC500V/1Min
Operation Force: 400gf max
Mechanical Life: 2000 operations Min
